292
4-5. Using the driving support systems
Hybrid system output
Braking force
Time
Hybrid system output restriction control begins operating
System determines that possibility of collision with detected object is high
Hybrid system output reduced
Example: Multi-information display: “BRAKE!”
Figure 3 When brake control operates
Hybrid system output
Braking force
A
B
C
D
E
F
G
A
B
