8-1. Specifications
*1
: Minimum pedal clearance when depressed with a force of 300 N (30.6 kgf, 67.4 lbf)
while the hybrid system is operating.
When performing the brake pedal inspection, also be sure to check that the brake sys-
tem warning light is not illuminated when the hybrid system is operating. (If the brake
system warning light is illuminated, refer to P.406)
*2
: Make sure to confirm that the brake system warning light (yellow) does not illuminate. (If
the brake system warning light illuminates, refer to P.406)
17-inch tires
Parking brake indicator
*2
When pushing the parking brake
switch for 1 to 2 seconds: comes on
When pulling the parking brake switch
for 1 to 2 seconds: turns off
Fluid type
SAE J1703 or FMVSS No. 116 DOT 3
SAE J1704 or FMVSS No.116 DOT 4
Steering
Free play Less than 30 mm (1.2 in.)
Tires and wheels
Tire size
215/55R17 94W
215/55R17 94V
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Vehicle speed Front tire and rear tire
More than 160 km/h (100
mph)
320 kPa (3.2 kgf/cm
2
or bar,
46 psi)
160 km/h (100 mph) or less
240 kPa (2.4 kgf/cm
2
or bar,
35 psi)
Wheel size 17 7 1/2J
Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf)
