High beam

Right or left turn

Lane change

(right or left)

Headlight flasher

Variable intermittent

operation

Washer on

High speed operation

Low speed operation

QUICK REFERENCE

6

D HEADLIGHT DIMMER SWITCH

D TURN SIGNAL SWITCH

6. WINDSHIELD WIPER AND

WASHER SWITCH

Variable intermittent windshield wipers
