ELECTRICAL COMPONENTS
395
No. FUSE AMPERE CIRCUIT
43
MIR
HTR
10
Outside rear view mirror
defogger
44 AM1 5 Starting system
45 FOG 15 Front fog lights
46
SUN−
SHADE
15 Rear sunshade
47 GAUGE2 10
Auto anti−glare inside rear
view mirror, compass, back−up
lights, automatic light control
system, automatic headlight
leveling system, cruise control
system, seat belt reminder
lights
48 PANEL 10
Glove box light, console box
light, clock, outside
temperature gauge,
multi−information display,
instrument cluster lights,
instrument panel lights
49 TAIL 10
Tail lights, parking lights,
license plate lights
50 PWR NO.4 20
Rear passenger’s power
window (left side)
No. FUSE AMPERE CIRCUIT
51 PWR NO.2 20
Front passenger’s door lock
system, front passenger’s
power window
52 OBD 7.5 On−board diagnosis system
53
SEAT
HTR
20 Seat ventilators/heaters
54 WASHER 15 Windshield washer
55
FAN
RLY
10 Electric cooling fans
56 STOP 15
Stop lights, high mounted
stoplight
57
FUEL
OPEN
5 Fuel filler door opener
58
DOOR
NO.2
25
Multiplex communication
system (power door lock
system, auto−door locking
system, wireless remote
control system)
59 AMP 25 Audio system
60 PWR NO.3 20
Rear passenger’s power
window (right side)
