S-Device Supervisor Object
17200138_002_C0 – (2016-10) –
 Leybold
11
Attr.
ID
Access
rule
NV/
V
Name DeviceNet
data type
Description of attribute
13 Get V Exception Detail
Alarm
STRUCT of: A structure of three structures
containing a bit mapped repre-
sentation of the alarm detail
Common
Exception Detail
STRUCT of:
Size 2 USINT Number of common detail bytes
Detail 0 ARRAY of:
→ "Semantics" section below.
Detail 1 BYTE
→ "Semantics" section below.
Device Exception
Detail
STRUCT of:
Size 4 USINT
Number of device detail bytes
≙ 4
Detail 0 ARRAY of: S-Analog Sensor Instance 1
(Pirani)
Sensor alarm byte 0
Detail 1 BYTE S-Analog Sensor Instance 1
(Pirani)
Sensor alarm byte 0
Detail 2 S-Analog Sensor Instance 2
(Hot cathode) Sensor Alarm byte
0
Detail 3 S-Analog Sensor Instance 2
(Hot cathode) Sensor alarm byte
1
Manufacturer
Exception Detail
STRUCT of:
Size 1 USINT Number of Manufacturer detail
bytes
Detail 0 ARRAY of: Serial communication alarm
14 Get V Exception Detail
Warning
STRUCT of: A structure of three structures
containing a bit mapped repre-
sentation of the warning detail
Common
Exception Detail
STRUCT of:
Size 2 USINT Number of Common Detail Bytes
Detail 0 ARRAY of:
→ "Semantics" section below.
Detail 1 BYTE
→ "Semantics" section below.
Device Exception
Detail
STRUCT of:
Size 5 USINT
Number of device detail bytes
≙ 5
Detail 0 ARRAY of: S-Analog Sensor object– >
Class Level Status Extension
Detail 1 BYTE S-Analog Sensor Instance 1
(Pirani)
Sensor Warning Byte 0
Detail 2 BYTE S-Analog Sensor Instance 1
(Pirani)
Sensor Warning Byte 1
Detail 3 S-Analog Sensor Instance 2
(hot cathode) Sensor Warning
Byte 0
Detail 4 S-Analog Sensor Instance 2
(hot cathode) Sensor Warning
Byte 1
Manufacturer
Exception Detail
STRUCT of:
Size 1 USINT Number of Manufacturer Detail
Bytes
Detail 0 Byte serial common warning
15 Set NV Alarm Enable BOOL
→ "Semantics" section below.
16 Set NV Warning Enable BOOL
→ "Semantics" section below.
