S-Device Supervisor Object
10
17200138_002_C0 – (2016-10) –
 Leybold
2.3 S-Device Supervisor Object
Class Code 30
h
= 48
d
2.3.1 Class Attributes
Attr.
ID
Access
rule
Name DeviceNet
data type
Description of
attribute
Semantics of values
1 Get Revision UINT Revision of this object The current value assigned
to this attribute is one (01).
If updates that require an
increase in this value are
made, then the value of this
attribute increases by one.
2 Get Max
Instance
UINT Maximum instance
number of an object
currently created in
this class level of the
device.
The largest Instance num-
ber of a created object at
this class hierarchy level.
2.3.2 Instance Attributes
Attr.
ID
Access
rule
NV/
V
Name DeviceNet
data type
Description of attribute
3 Get NV DeviceType SHORT
STRING
ASCII Text, "CG" combination
gauge
4 Get NV SEMI Standard
Revision Level
SHORT
STRING
Specifies the revision level of the
SEMI S/A network standard to
which the device complies ("E54-
0997").
5 Get NV Manufacturer’s
Name
SHORT
STRING
6 Get NV Manufacturer’s
Model Number
SHORT
STRING
ITR 200 SD
7 Get NV Software Revision
Level
SHORT
STRING
ASCII Text, for example "xxxyyy"
xxx
≙ version of the measuring
print
yyy
≙ version of the DeviceNet
print
8 Get NV Hardware Revision
Level
SHORT
STRING
ASCII text, for example "1.001"
9 Get NV Manufacturer’s
Serial Number
SHORT
STRING
ASCII text
10 Get NV Device
Configuration
SHORT
STRING
Depending on device configura-
tion (→  9)
11 Get V Device Status USINT
→ "Semantics" section below.
12 Get V Exception Status BYTE
→ "Semantics" section below.
