I/O Assembly Object
28
17200138_002_C0 – (2016-10) –
 Leybold
3 I/O Assembly Object
Class Code 04
h
A collection of assembly objects allows the sending of attributes from different
application objects in one message (i.e. Polling I/O).
3.1 I/O Assembly Instances
The following table identifies the I/O assembly instances supported by the
transmitter device.
Number Type Name
1 Input Pressure Value (Active Instance)
2 Input Exception Status and INT Pressure Value (Active Instance)
4 Input REAL Pressure Value (Active Instance)
5 Input Exception Status and REAL Pressure Value (Active Instance)
8 Input Exception Status
9 Input Active Instance, Active Pressure Value
10 Input Exception Status and Active Instance and INT Active Pressure Value
12 Input Active Instance
REAL Active Pressure Value
13 Input Exception Status
Active Instance
REAL Active Pressure Value
