Identity Object
17200138_002_C0 – (2016-10) –
 Leybold
9
2.2 Identity Object
Class Code 01
h
= 01
d
2.2.1 Class Attributes
This object provides identification of and general information about the device.
Attr.
ID
Access
rule
Name DeviceNet
Data Type
Description of attribute Semantics of values
1 Get Revision UINT Revision of this object.
Note: All class defini-
tions are required to
include this class
attribute.
The current value as-
signed to this attribute is
one (01). If updates that
require an increase in
this value are made,
then the value of this
attribute increases by
one.
2 Get Max
Instance
UINT Maximum instance
number of an object
currently created in this
class level of the device.
The largest instance
number of a created
object at this class
hierarchy level.
2.2.2 Instance Attributes
Attr.
ID
Access
rule
NV/
V
Name DeviceNet
data type
Description of attribute
1 Get NV Vendor ID UINT 79 02 Manufacturer identification
Value: 633
2 Get NV Device Type UINT 1C
h
= Vacuum pressure
gauge
3 Get NV Product Code UINT 12
4 Get NV Revision STRUCT
5 Get NV Status WORD
6 Get NV Serial Number UDINT
7 Get NV Product Name SHORT STRING ITR 200 SD
Service Code Name Description
5 (05
h
) Reset 0 = last installation,
1 = default installation
14 (0E
h
) Get_Attribute_Single
Services
