Manual CT26-15 - LFB
29
8. TECHNICAL DATA
PARTS
MAXIMUMN TORQUE
FOR CLAMPING (NM)
Pedals crank axle 30 - 40
Pedal 18 - 25
Front wheel axle 18 - 25
Rear wheel axle 30 - 40
Seat post 18 - 25
Stem and handlebars 18 - 25
Angle saddle 18 - 25
CHARACTERISTICS
MODEL CT26-15
Size between the wheel (mm) 1080
Total weight (including battery) (kg) 25
Maximum load 120
Assitance maximum speed (km/h) 25
Range
(For a load of 75kg and with the ECO level assist)
55
Battery
Lithium Ion
600 cycles
Voltage (v) 37V
Motor Brushless
Motor power (w) 250 watts
Charger voltage 42V
Dimension of the tire 26’x1.7
Pressure of the tire 2.8 à 4.5 bars
Derailleur SHIMANO Indexed control
Developpement 14, 16, 18, 21, 24, 28
Chainring (number of teeth) 42
