Assembly the front wheel:
Position the washers on the wheel axle. Lift the bike and insert the wheel spindle in the bottom of the legs
of the fork.
Control the washers position as well as the centering of the wheel. Screw the wheel nuts. Alternately on each
side gradually tighten the wheel nuts (tightening 18-25 Nm).
If the wheel is not centered, loosen nuts and start again.
r
do not touch the sMall nuts oF the axle
,
you May daMage May daMage the bearings.
Adjust your brake again (See: 2.3).
2.5.2 Rear wheel
r
this operation is to be perForMed by a proFessional, but in case you would like to do it,here is the
procedure to Follow.
 Required tools: wrench of 19 mm.
Disassembly of the rear wheel:
Disconnect the motor (located right side of the connection ebike on the lower horizontal part of the frame).
Cut «Colson» link xing the motor cable to the frame. Remove nuts caches right and left. Loosen the nuts.
Remove the nuts and wheel axle washers. Loosen the brake cable V-Brake clamp to release the pads in order
to remove the wheel.
Release the chain sprocket wheel with special attention to the tilting of the chain.
Remove the wheel from the frame forward and remove the chain wheel axis.
