2.1 Saddle settings
Key 13 mm.
2.1.1 Angle
Nut.
Loosen the nut under the saddle.
Adjust the angle of the saddle, in order to get the best for your comfort position. Tighten the nut (tightening
torque 25 Nm).
2.1.2 Height
The ebike saddle enables a lower position than on a conventional bike. With the electric assistance you will
provide less effort and you can be sitted at a lower position for better safety. The required sizes of the user
(rider) for optimum use of the bicycle is between 1.50 and 1.90m. So, adjust your seating position seat height
according to the following indications:
Loosen the quick release of the saddle tube.
Quick release.
Sitting on the saddle with shoes suitable for cycling, place a pedal in the down position, place one heel on
the pedal, the leg must fall normally without being stiff. Raise or lower the saddle to get the correct height.
