**Note: TV brackets can be attached with M4 x 35
screws (MM), M6 x 35 screws (NN), M8 x 35 screws
(OO), or M8 x 45 screws (PP) depending on your TV.
Hardware Used
QQ
1b
M4 x 35 Screw
M6 x 35Screw
M8 x 35 Screw
M8 Washer
M8 x45 Screw
5 mm Spacer
14 mm Spacer
MM
NN
OO
PP
RR
SS
TT
x8
x8
x4
x4
x4
x4
x4
1b. For curved back flat panel: Secure TV brackets (B)
and (C) with four spacers (*), four washers (QQ), and
four screws (**).
*Note: 5 mm spacers (SS) or 14 mm spacers (TT) can
be used depending on your TV.
ASSEMBLY INSTRUCTIONS
8
To Next Page
