2. If the screws are too long, additional 5 mm spacers
(SS), 14 mm spacers (TT) and washers (RR) may
be needed.
Hardware Used
Wood Stud Installation
Note: For concrete, proceed to step 9.
3. Use a stud finder not included to locate wood studs.
Mark the edge, and center location.
M8 Washer
5 mm Spacer
14 mm Spacer
RR
SS
TT
2
3
TT
RR
SS
RR
x4
x8
x8
9
ASSEMBLY INSTRUCTIONS
To Next Page
