LG 17MB15T User Manual

A11
Control Panel Functions
This Indicator lights up as blue when the display is
operating normally(On Mode). If the display is in
Sleep Mode (Energy Saving), this indicator changes
to flicker.
Use this button to turn the display on or off.
Power Button
Power Indicator
Use this button to select an icon in the On Screen
Display.
AUTO/SET
Button
AUTO IMAGE ADJUSTMENT
When adjusting your display settings, always press
the AUTO/SET button prior to entering the On
Screen Display(OSD). This will automatically adjust
your display image to the ideal settings for the
current screen resolution size (display mode).
The best display mode is:
: 1280 x 1024
: 1280 x 1024
Buttons
Use these buttons to select or adjust functions in the On
Screen Display.
For more information, refer to page A18.
Control Function

LG 17MB15T Specifications

General

Pixel pitch	0.264 x 0.264 mm
Screen shape	Flat
Display diagonal	17 \
Touchscreen type	Multi-user
Display resolution	1280 x 1024 pixels
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Certification	UL(cUL)\\r TUV-GS\\r TUV-típus\\r FCC-B, CE\\r EPA
Product color	Black
Cables included	AC, VGA
Full HD	No
Dimensions (W x D x H) with stand	370 x 95 x 315 mm
Tilt angle range	-15 - 68 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
Package depth	377 mm
Package width	429 mm
Package height	159 mm
Package weight	4500 g

Weight and Dimensions

Depth (with stand)	95 mm
Width (with stand)	370 mm
Height (with stand)	315 mm
Weight (with stand)	3300 g
Height (without stand)	62 mm
Weight (without stand)	2900 g
