LG 17MB15T User Manual

A19
Troubleshooting
No image appears
Check the following before calling for service.
No image appears
Do you see a "OSD LOCKED" message on the screen?
● Is the power cord of the
display connected?
● Is the power indicator
light on?
● Is the power on and the
power indicator blue or
green?
● Is the power indicator
flickering?
● Do you see an "OUT OF
RANGE" message on
the screen?
● Do you see a "CHECK
SIGNAL CABLE"
message on the
screen?
• Check and see if the power cord is connected
properly to the power outlet.
•
Press the Power button.
• Adjust the brightness and the contrast.
• If the display is in power saving mode, try moving
the mouse or pressing any key on the keyboard to
bring up the screen.
• Try to turn on the PC .
• This message appears when the signal from the
PC (video card) is out of horizontal or vertical
frequency range of the display. See the
'Specifications' section of this manual and
configure your display again.
• This message appears when the signal cable
between your PC and your display is not
connected. Check the signal cable and try again.
• You can secure the current control settings,
so that they cannot be inadvertently changed.
You can unlock the OSD controls at any time
by pushing the MENU button for several
seconds: the message
“OSD UNLOCKED” will appear.
●
Do you see “OSD
LOCKED” when you
push MENU button?

LG 17MB15T Specifications

General

Pixel pitch	0.264 x 0.264 mm
Screen shape	Flat
Display diagonal	17 \
Touchscreen type	Multi-user
Display resolution	1280 x 1024 pixels
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Certification	UL(cUL)\\r TUV-GS\\r TUV-típus\\r FCC-B, CE\\r EPA
Product color	Black
Cables included	AC, VGA
Full HD	No
Dimensions (W x D x H) with stand	370 x 95 x 315 mm
Tilt angle range	-15 - 68 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
Package depth	377 mm
Package width	429 mm
Package height	159 mm
Package weight	4500 g

Weight and Dimensions

Depth (with stand)	95 mm
Width (with stand)	370 mm
Height (with stand)	315 mm
Weight (with stand)	3300 g
Height (without stand)	62 mm
Weight (without stand)	2900 g
