LG 17MB15T User Manual

A15
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
BRIGHTNESS
CONTRAST
GAMMA
To adjust the brightness of the screen.
To adjust the contrast of the screen.
Set your own gamma value. : -50/0/50
On the monitor, high gamma values
display whitish images and low gamma
values display blackish images.
PRESET
RED
GREEN
BLUE
• sRGB: Set the screen color to fit the
sRGB standard color
specification.
• 6500K: Slightly reddish white.
• 9300K: Slightly bluish white.
Set your own red color levels.
Set your own green color levels.
Set your own blue color levels.
COLOR
MENU : Exit
: Decrease
: Increase
SET : Select another
sub-menu
MENU : Exit
: Decrease
: Increase
SET : Select another
sub-menu

LG 17MB15T Specifications

General

Pixel pitch	0.264 x 0.264 mm
Screen shape	Flat
Display diagonal	17 \
Touchscreen type	Multi-user
Display resolution	1280 x 1024 pixels
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Certification	UL(cUL)\\r TUV-GS\\r TUV-típus\\r FCC-B, CE\\r EPA
Product color	Black
Cables included	AC, VGA
Full HD	No
Dimensions (W x D x H) with stand	370 x 95 x 315 mm
Tilt angle range	-15 - 68 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
Package depth	377 mm
Package width	429 mm
Package height	159 mm
Package weight	4500 g

Weight and Dimensions

Depth (with stand)	95 mm
Width (with stand)	370 mm
Height (with stand)	315 mm
Weight (with stand)	3300 g
Height (without stand)	62 mm
Weight (without stand)	2900 g
