45
ENGLISH
SPECIFICATIONS
Panel Screen Type 660 mm Wide (26 inch)
Visible diagonal size : 660 mm
Pixel Pitch 0.4215 mm (H) x 0.4215 mm (V)
Video Signal Max. Resolution 1366 × 768 @ 60 Hz
Recommended Resolution 1366 × 768 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub analogue, CVBS, HDMI, USB
Speaker Out 5 W x 2
Power Rated Voltage 19 V 2.0 A
Power Consumption On Mode 35 W (typ.)
Off Mode : 0.5 W
Dimensions (Width x Depth x Height)
Weight
With Stand
620.4 mm x 162.1 mm x 432.2 mm
4.2 kg
Without Stand
620.4 mm x 58.8 mm x 380.5 mm
3.9 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
26MA33A
