46
ENGLISH
SPECIFICATIONS
28MN30A
Panel Screen Type 700 mm Wide (28 inch)
Visible diagonal size : 700 mm
Pixel Pitch 444.75 um x 149.75 um x RGB
Video Signal Max. Resolution 1366 × 768 @ 60 Hz
Recommended Resolution 1366 × 768 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub analogue, CVBS, HDMI, USB
Speaker Out 5 W x 2
Power Rated Voltage 19 V 2.0 A
Power Consumption On Mode 35 W (typ.)
Off Mode : 0.5 W
Dimensions (Width x Depth x Height)
Weight
With Stand
645.3 mm x 182.1 mm x 447.9 mm
5.1 kg
Without Stand
645.3 mm x 78.7 mm x 401.6 mm
4.7 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
