47
ENGLISH
SPECIFICATIONS
Panel Screen Type 720 mm Wide (29 inch)
Visible diagonal size : 720 mm
Pixel Pitch 154 um (H) x 462 um (V)
Video Signal Max. Resolution 1366 × 768 @ 60 Hz
Recommended Resolution 1366 × 768 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub Analogue, CVBS, HDMI, USB
Speaker Out 5 W x 2
Power Rated Voltage 19 V 2.4 A
Power Consumption On Mode : 40 W (typ.)
Off Mode : 0.5 W
Dimensions (Width x Depth x Height)
Weight
With Stand
668.6 mm x 182.1 mm x 457 mm
5.7 kg
Without Stand
668.6 mm x 81.9 mm x 405.5 mm
5.4 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
29MN33A
