LG 23MP75HM User Manual

2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3 ASSEMBLING AND PREPAR-
ING
3 Unpacking
4 Parts and buttons
5 Setting up the Monitor set
5 - Attaching the Stand Base
5 - Detaching the Stand Base
6 - Mounting on a table
6 - Using the cable holder
8 - Mounting on a wall
9 USING THE MONITOR SET
9 Connecting to a PC
9 - D-SUB connection
9 - HDMI connection
10 - Peripheral device connection
11 CUSTOMIZING SETTINGS
12 Customizing Settings
12 - Menu Settings
13 - Picture
14 - Color
15 - Display
15 - Audio
16 - Others
17 READER Setting
18 FUNC. Setting
18 - SUPER ENERGY SAVING
19 - Picture Mode
20 - SUPER RESOLUTION +
21 - DUAL DISPLAY
21 - DUAL WEB
22 TROUBLESHOOTING
24 SPECIFICATIONS
24 23MP75HM
25 27MP75HM
26 Preset Modes (Resolution)
26 Indicator
27 PROPER POSTURE
27 Proper posture for using the Monitor set.

LG 23MP75HM Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Display surface	-
Display diagonal	23 \
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
USB Type-A downstream ports quantity	0
Certification	UL(cUL)\\r TUVTYPE\\r FCCB, CE\\r EPA 6.0
Product color	Black
LED indicators	Power
Tilt angle range	5 - 20 °
Number of OSD languages	17
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	21 W
Sustainability certificates	EPEAT Gold
Package depth	131 mm
Package width	620 mm
Package height	394 mm
Package weight	5510 g
Cables included	AC, VGA

Weight and Dimensions

Depth (with stand)	182 mm
Height (with stand)	423 mm
Weight (with stand)	3950 g
Depth (without stand)	73 mm
Width (without stand)	533 mm
Height (without stand)	320 mm
Weight (without stand)	3050 g
