LG 24BK550Y Service Manual

- 4 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specications and others are subject to change without notice for improvement.
1. General Specication
No Item
Content Remark
1 Customer BRAND
2 User Model Name 24/27BK550Y
3 Sale region Refer to Suffix standard
4 Feature 24/27” LCD MONITOR
5 Chassis Name LM6JA
6
General
Scope
External SW
&Adj.
Tact Key (Menu, Left, Right, Up, Down, OK/Input, Power)
Function
OSD,DDC2B,DDC2AB, HDCP, OSD Lock, Ratio, Smart
Energy Saving, Color Weakness, SUPER
RESOLUTION+, Black Level, Black
Stabilizer, OnScreen Control
7
Input &
Output
HDMI IN - 1ea at the back
DVI IN - 1ea at the back
DP IN DP 1.2 1ea at the back
D_SUB IN - 1ea at the back
AUDIO IN Audio L/R IN 1ea at the back
HP OUT Audio L/R OUT 1ea at the back
Speaker Speaker L/R(1.2W Setting) Bottom
USB 1UP, 2Down
8 Power Cord
Length : 1.8±0.05M
Shape : Wall-out
Color : Black
Length : 1.2±0.05M(DC cable length)
1.0±0.05M(power cord)
Shape : desktop
Color : Black
Refer to Suffix
standard and power
cord table
9 Cable
Signal Cable
(DP)
Length : 1.8m
Shape : Detachable Type
Color : Black
Pin : Triple Row, 20 Pin DP
Refer to Suffix
standard
Signal Cable
(HDMI)
Length : 1.8m
Shape : Detachable Type
Color : Black
Pin : 19Pin HDMI
Refer to Suffix
standard
Signal Cable
(DVI)
Length : 1.8m
Shape : Detachable Type
Color : Black
Pin : 24Pin DVI
Refer to Suffix
standard
Audio
Length : 1.8m
Color: Black ,
Pin:2P
Refer to Suffix
standard
10 Power Input: AC100~240V 50~60Hz,1.5A Max Built-in PSU

LG 24BK550Y Specifications

General

3D	No
DDC/CI	Yes
Color gamut	72 %
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display diagonal	24 \
Display technology	LED
Native aspect ratio	16:9
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	18
Panel mounting interface	100 x 100 mm
USB hub version	2.0
Number of upstream ports	1
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Gold, ENERGY STAR
RMS rated power	2 W
On/off switch	-
Certification	TCO 7.0, UL (cUL), TUV-GS, TUV-Ergo, FCC-B, THIS, ISO13406-2, Windows 10
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18.2 W
Power consumption (PowerSave)	- W
Package depth	178 mm
Package width	627 mm
Package height	505 mm
Package weight	7900 g
Cables included	AC, Audio (3.5mm), DVI, DisplayPort, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	240 mm
Width (with stand)	553.8 mm
Height (with stand)	382.9 mm
Weight (with stand)	5700 g
Depth (without stand)	58.4 mm
Height (without stand)	331.8 mm
Weight (without stand)	3600 g
