30
Detaching the Stand Body
1 Place the monitor’s screen face down. To protect
the screen from scratches, cover the surface with a
soft cloth.
2 Remove the stand from the monitor by pressing
the button on the bottom center of the back of the
monitor.
Installing the wall mount plate
This monitor supports the specification of the standard
wall mount plate or compatible device.
1 Place the screen face down. To protect the screen
from scratches, cover the surface with a soft cloth.
2 Using a screwdriver, remove the four screws at the
back of the monitor.
3 Place the wall mount plate onto the monitor and
align it with the screw holes.
4 Tighten the four screws to fix the plate to the
monitor using a screwdriver.
NOTE
The wall mount plate is sold separately.
For more information on installation, refer to the wall
mount plate's installation guide.
Be careful not to use excessive force when mounting
the wall mount plate, as this can damage the
monitor's screen.
