PREPARATION
19
VESA WALL MOUNTING
For proper ventilation, allow a clearance of 4inches on each side from the wall.
4 inches
4 inches
DESKTOP PEDESTAL INSTALLATION
GG
Ensure adequate ventilation by following the clearance recommendations.
CAUTION
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
GG
Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
!
R
100 mm
200 mm
( )
ANTENNA IN
M.P.I.
400mm
(32LC5DC*:
100mm)
600 mm
(32LC5DC*:200mm)
32/37/42LC5DC* 32LX5DC*
400 mm
600 mm
42PX8DC
4 inches
32/37/42LC5DC*
32LX5DC*
42PX8DC
INPUTINPUT
ENTERENTER
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches

Table of Contents

Other manuals for LG 32LX5DC

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG 32LX5DC and is the answer not in the manual?

LG 32LX5DC Specifications

Display IconDisplay
display size32"
display area31.5"
aspect ratio16:9
native resolution1366×768
maximum computer resolution1024×768
brightness500 cd/m²
contrast ratio1600:1
viewing angle178°
color depth16.7 Million
lamp lifeApprox. 60, 000 Hours
response time8 ms
Audio IconAudio
audio power30W (15W×2)
Power IconPower
power source100~240V (50/60Hz)
power consumption190W
Dimensions and Weight IconDimensions and Weight
dimensions with stand36.3"×24.19"×11.32"
dimensions without stand36.3"×21.47"×3.8"
packaging dimensions38.7"×27.44"×14.02"
weight with stand39.0 lbs.
weight without stand30.4 lbs.
weight with packaging46.1 lbs.
