LG 32LX5DC User Manual

EXTERNAL EQUIPMENT SETUP
27
GG
Do not connect to both Video
and S-Video at the same time. In
the event that you connect both
Video and the S-Video cables,
only the S-Video will work.
CAUTION
When connecting with a RCA cable
GG
The picture quality is improved: compared to normal
composite (RCA cable) input.
NOTE
!
AUDIO
REMOTE
CONTROL
OUT
R
RESET
UPDATE
M.P.I.
SERV
SPEAKE
OUT
8
AV IN 1
T IN
TAL
DIO
UT
CAL)
AUDIO
MONO
( )
S-VIDEO
VIDEO
( )
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
ANTENNA IN
M.P.I.
( )
AUDIO
REMOTE
CONTROL
OUT
RESET
UPDATE
M.P.I.
SER
SPEAK
OUT
8
AV IN 1
ENT IN
GITAL
AUDIO
OUT
PTICAL)
AUDIO
MONO
( )
S-VIDEO
VIDEO
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
ANTENNA IN
M.P.I.
Connect the
AAUUDDIIOO
/
VVIIDDEEOO
jacks between TV and
VCR. Match the jack colors (Video = yellow, Audio Left
= white, and Audio Right = red)
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the
VCR.
(
Refer to the VCR owner’s manual.
)
■
Select
AAVV 11
input source with using the
IINNPPUUTT
button on
the remote control.
■
If connected to
AAVV IINN22
, select
AAVV22
input source.
When connecting with an S-Video cable
Connect the S-VIDEO output of the VCR to the
SS --VVIIDDEEOO
input on the set.
Connect the audio outputs of the VCR to the
AAUUDDIIOO
input jacks on the set.
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the VCR.
(
Refer to the VCR owner’s manual.
)
■
Select
AAVV 11
input source with using the
IINNPPUUTT
button on
the remote control.
■
If connected to
AAVV IINN22
, select
AAVV22
input source.
1
2
1
GG
If you have a mono VCR, con-
nect the audio cable from the
VCR to the
AAUUDDIIOO
LL//MMOONNOO
jack of the set.
NOTE
!
1
1
2

LG 32LX5DC Specifications

Display

display size	32"
display area	31.5"
aspect ratio	16:9
native resolution	1366×768
maximum computer resolution	1024×768
brightness	500 cd/m²
contrast ratio	1600:1
viewing angle	178°
color depth	16.7 Million
lamp life	Approx. 60, 000 Hours
response time	8 ms

Audio

audio power	30W (15W×2)

Power

power source	100~240V (50/60Hz)
power consumption	190W

Dimensions and Weight

dimensions with stand	36.3"×24.19"×11.32"
dimensions without stand	36.3"×21.47"×3.8"
packaging dimensions	38.7"×27.44"×14.02"
weight with stand	39.0 lbs.
weight without stand	30.4 lbs.
weight with packaging	46.1 lbs.
