APPENDIX
114
APPENDIX
2200.. GGrreeeenn AAddjjuussttmmeenntt((CCoommmmaanndd::ww))
To adjust green in colour temperature.
Transmission [k][w][ ][Set ID][][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2" as shown below
Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x]
2211.. BBlluuee aaddjjuussttmmeenntt((CCoommmmaanndd::$$))
To adjust blue in colour temperature.
Transmission [k][$][ ][Set ID][][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2".
Acknowledgement [$][ ][Set ID][][OK/NG][Data][x]]
*In User Mode, Colour Temperature is abailabe.
*Real data mapping 2
0 : -20
5 : -19
A : -18
5F: -1
64: 0
69: +1
C3 : +19
C8 : +20
2222.. CChhaannnneell TTuunniinngg ((CCoommmmaanndd:: mm aa))
To tune channel to following programme number
Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1]
[ ][Data2][Cr]
Data 0: High channel data
Data 1: Low channel data
Data 2: 00: Analogue TV
: 10: Digital TV
ex) Analogue TV : ma 0 00 01 00
* Channel Data Range:
Analogue TV: 0 ~ 63
Digital TV: 0 ~ 3E
2233.. IISSMM MMeetthhoodd ((CCoommmmaanndd22::pp))
To control the ISM method. You can also adjust ISM
method in OPTION menu.
This feature is not available for all models.
Transmission [ j ][p][ ][Set ID][ ][Data][Cr]
Data 0: Normal Data 1: Orbiter
Data 2: Inversion Data 3: White Wash
Acknowledgement [p][ ][Set ID][ ][OK/NG][Data][x]
2244.. LLooww PPoowweerr ((CCoommmmaanndd22::qq))
To reduce the power consumption of the set. You can
also adjust Low power in OPTION menu.
This feature is not available for all models.
Transmission [ j ][q][ ][Set ID][ ][Data][Cr]
Data 0: low power off
1: low power on
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
2255.. OOrrbbiitteerr TTiimmee SSeettttiinngg ((CCoommmmaanndd22::rr))
To adjust orbiter operation time term.
This feature is not available for all models.
Transmission [ j ][r][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: FE(*transmit by Hexadecimal code),
Unit: Second
*Refer to ‘Real data mapping1’. See page 112.
Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x]
2266.. OOrrbbiitteerr PPiixxeell SSeettttiinngg ((CCoommmmaanndd22::ss))
To adjust pixel number in orbiter function.
This feature is not available for all models.
Transmission [ j ][s][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: 3
*Refer to ‘Real data mapping1’. See page 112.
Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x]
2277.. SSeenndd IIRR CCooddee ((CCoommmmaanndd:: mm cc))
To send IR remote key code
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Data Key code: Refer to page 108.
Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]
2288.. IInnppuutt SSeelleecctt((CCoommmmaanndd:: xx bb))
To select input source for TV.
Transmission [x][b][ ][Set ID][ ][Data][Cr]
Data 00 : Digital Data 41 : Component2
Data 10 : Analogue Data 50 : RGB-PC
Data 20 : AV1 Data 90 : HDMI1
Data 21 : AV2 Data 91 : HDMI2
Data 40 : Component1 Data 92 : HDMI3
Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]
