EXTERNAL EQUIPMENT SETUP
19
When connecting with HDMI cable
Connect the digital set-top box to
HHDDMMII//DDVVII IINN11
,
22
or
33
jack on the set.
No separate audio connection is necessary.
Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
Select
HHDDMMII11
,
HHDDMMII22
or
HHDDMMII33
input source using the
IINNPPUUTT
button on the remote control.
2
1
GG
If the digital set-top box supports Auto HDMI function, the
output resolution of the source device will be automatically
set to 1280x720p.
GG
If the digital set-top box player does not support Auto
HDMI, you need to set the output resolution appropriately.
To get the best picture quality, adjust the output resolution
of the source device to 1920x1080i/1080p. (32LB9D*,
42/50PB4D*: 1280x720p)
NOTE
!
3
4
RGB IN
RGB (PC)
DIGITAL
AUDIO OUT
COMPONENT IN
VIDEO AUDIO
COMPONENT IN
VIDEO AUDIO
DIGITAL
AUDIO OUT
RGB IN
RGB (PC)
AUDIO
(RGB/DVI)
COMPONENT INCOMPONENT IN
VIDEOVIDEO AUDAUDIO
RGB INRGB IN
RGB (PC) RGB (PC)
AUDIO
(RGB/DVI)
DIGITAL
AUDIO OUT
HDMI/DVI INHDMI/DVI IN
2
1
HDMI-DTV OUTPUT
COMPONENT IN
VIDEO AUDIO
DIGITAL
AUDIO OUT
HDMI/DVI IN
RGB IN
AUDIO
(RGB/DVI)
3
1
