LG 42LC2D Service Manual

- 24 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
30919E0047A CABINET ASSEMBLY, 42LC2D BRAND 30909E0028 USA
30919E0047F CABINET ASSEMBLY, 42LC2D BRAND 30909E0028 UD C/SKD
6304FLP295A
LCD(LIQUID CRYSTAL DISPLAY), LC420W02-B6K1 LG PHILPS TFT COLOR B6+STATUS PIN
or 6304FLP353A LCD(LIQUID CRYSTAL DISPLAY), LC420W02-B6K2 LG PHILIPS TFT COLOR BDF P6
3809900165A BACK COVER ASSEMBLY, 42LC2 2PHONE USA
3809900165D BACK COVER ASSEMBLY, 42LC2 2PHONE USA C/SKD
3043900034B TILT SWIVEL ASSEMBLY, 42LC2 42LC2 FOR USA
3043900034D TILT SWIVEL ASSEMBLY, 42LC2 42LC2 42LC2 C/SKD
49519S0036A METAL ASSEMBLY, FRAME, MAIN 42LC2D-UD/ND
49519S0036D METAL ASSEMBLY, FRAME, MAIN 42LC2D-UD C/SKD
68719ST913A PWB(PCB) ASSEMBLY,SUB, SUB T.T LA51D 42LC2D-UD ALUSLLX KEY TOTAL ASSY
6400WMCX03A
SPEAKER,WOOFER, G1560102 MACOM WOOFER 8OHM 15/20W 82DB OTHERS 100HZ 193*57MM
6400DTTX02A SPEAKER,TWEETER, EN15D-6629 TOPTONE TWEETER(DOME) 8OHM 15/20W 78DB OTHERS LC2 MODEL
68719ST914A PWB(PCB) ASSEMBLY, SUB, SUB T.T LA51D 42LC2D-UD ALUSLLX IR TOTAL ASSY
4980V00390A SUPPORTER, NUT(3200KN0001A) BS SK-011T
6709900017A POWER SUPPLY ASSEMBLY, 42INCH H3/E2 LCD MODEL LCD YY LB LC 42INCH
68719ST920A PWB(PCB) ASSEMBLY,SUB, SUB T.T LA51D 42LC2D-UD ALUSLLX AV TOTAL
31419SNJ81A CHASSIS ASSEMBLY, SUB LA51D AC INLET ASSY
33139D4012A MAIN TOTAL ASSEMBLY, 42LC2D-UD BRAND LA51D
33139D4012B MAIN TOTAL ASSEMBLY, 42LC2D-UD(SKD) BRAND LA51D
68719STA37A PWB(PCB) ASSEMBLY,SUB, SUB T.T LA51D 42LC2D-UD ALUSLL SIDE AV TOTAL ASSY
49519K0115F METAL ASSEMBLY, SHIELD, MAIN DIGITAL 42LC2D-UD
49519K0115L METAL ASSEMBLY, SHIELD, MAIN DIGITAL 42LC2D-UD(C/SKD)
