LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R704 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R705 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R706 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R707 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R708 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R710 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R711 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R712 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R715 0RJ0512D677 51 OHM 1/10 W 5% 1608 R/TP
R716 0RJ0512D677 51 OHM 1/10 W 5% 1608 R/TP
R718 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R719 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R720 0RJ6801D677 6800 OHM 1/10 W 5% 1608 R/T
R721 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R722 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R723 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R725 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/T
R726 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R727 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R728 0RJ0272D677 27 OHM 1/10 W 5% 1608 R/TP
R729 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R730 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R731 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R732 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R733 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R8 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R802 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R818 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R835 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R901 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R902 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R903 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R904 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R905 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R906 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R907 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R908 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R910 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R911 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R912 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R913 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R918 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R920 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R921 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R922 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R923 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R925 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R930 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R931 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R932 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R933 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R934 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R935 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R937 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R938 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R939 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R940 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R941 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R942 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R943 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R953 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R958 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R967 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R968 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R972 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R974 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R975 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R976 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R977 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R988 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB101 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB102 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB104 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB106 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
RB107 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB111 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB112 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
RB113 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
RB114 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB115 0RJ1004D677 1000000 OHM 1/10 W 5% 1608
RB116 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB118 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB119 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB120 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB121 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB122 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB126 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
RB127 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB129 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB130 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
RB132 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB133 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB135 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB136 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB138 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
RB139 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB140 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
RB141 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB144 0RJ1004D677 1000000 OHM 1/10 W 5% 1608
RB146 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB201 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB202 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB205 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RB900 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB901 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB902 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB903 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB904 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB905 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB906 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB907 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB908 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB909 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB910 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB911 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB922 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB923 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB924 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB925 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB926 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB927 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB928 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB929 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB930 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB931 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
D1100 0DL233309AC SAM2333 TP KWANG GREEN/RED
D1101 0DL233309AC SAM2333 TP KWANG GREEN/RED
D202 0DL233309AC SAM2333 TP KWANG GREEN/RED
D203 0DL233309AC SAM2333 TP KWANG GREEN/RED
LED802 0DL233309AC SAM2333 TP KWANG GREEN/RED
VX500 6204B60001B VCXO BUBANG 27MHZ +/- 100 P
X1100 6204B47985K BMS-873R BUBANG 25MHZ +/- 5
X100 6212AB2015E HC-49/SM BUBANG 10.0MHZ +/-
X1000 6202VDT002H SX-1 SUNNY 18.432000MHZ +/-
X102 6202VDT002D SX-1SMD SUNNY RADIAL 8.0MHZ
X300 6212AB2806A SX-1 SUNNY 24.576MHZ +/- 50
X600 6212AB2845A ABLS-27.000MHZ-16-B-4Y-F-T
SW101 140-313A TACT 2LEAD 100G(TA) LG C&D
TU1100 6700AN0002C TDVS-H702P LGIT ATSC/NTSC D
C103 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
- 35 -
OTHERs
AV BOARD
CAPACITOR
