LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
IC306 0IPRPM3002D "MST9883C-LF-110 MSTAR 80P,L"
IC507 0IPRP00668A "IDT2309A-1DCG IDT 16P,SOIC"
IC600 0IPRPS5005A SII9011CLU(PB FREE) SILICON
IC701 0ICB533100A CS5331A-KSR 8SOIC TP ADC -
IC704 0ICB841500B CS8415A-CZR 28P TSSOP R/TP
IC1000 0IMCRSH001A "PQ05DZ1U SHARP 5, SMD TYPE"
IC1001 0IMCRSH001A "PQ05DZ1U SHARP 5, SMD TYPE"
IC1005 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC1006 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC1007 0IPMGA0010A AZ1117H-3.3 AAC SOT-223 3P
IC1008 0IMCRFA010A "KA7809R, FAIRCHILD 2P D-PAK"
IC1009 0IPMGA0010A AZ1117H-3.3 AAC SOT-223 3P
IC101 0IKE702900G KIA7029AF SOT-89 TP 2.9V VO
IC110 0IKE704200J KIA7042AF SOT-89 TP 4.2V VO
IC301 0IPMGSG018C LD1086DT15TR SGS-THOMSON 2P
IC305 0IPMGA0010A AZ1117H-3.3 AAC SOT-223 3P
IC401 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC603 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC703 0IPMGKE032A KIA78R09F KEC 5PIN DPAK R/T
IC802 0IMCRSJ001B SC1565IST-2.5TR 2.5V 1.5A S
IC803 0IMCRSH001A "PQ05DZ1U SHARP 5, SMD TYPE"
IC900 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC906 0IPMGA0010A AZ1117H-3.3 AAC SOT-223 3P
IC103 0IPH741400E 74HC14D 14SOP TP SHITTER TR
IC700 0IMCRFA013A 74LCX244MTC FAIRCHILD 20P T
IC702 0ISTL00029A "MC33078DR2G,LF ON SEMI 8P,S"
L1013 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1014 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1015 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1025 6140VB0032A DBF-1015A DONGBANG DIGITECH
L1026 6140VB0032A DBF-1015A DONGBANG DIGITECH
L1027 6140VB0032A DBF-1015A DONGBANG DIGITECH
L1028 6140VB0032A DBF-1015A DONGBANG DIGITECH
L802 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L803 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1000 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1005 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1010 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1034 6210TCE001S HU-1M2012-121 CERATECH 2012
L1035 6210TCE001S HU-1M2012-121 CERATECH 2012
L1036 6210TCE001S HU-1M2012-121 CERATECH 2012
L1037 6210TCE001S HU-1M2012-121 CERATECH 2012
L104 0LCML00003B MLB-201209-0120P-N2 5A MAG
L105 0LCML00003B MLB-201209-0120P-N2 5A MAG
L107 0LCML00003B MLB-201209-0120P-N2 5A MAG
L108 0LCML00003B MLB-201209-0120P-N2 5A MAG
L109 0LCML00003B MLB-201209-0120P-N2 5A MAG
L302 0LCML00003B MLB-201209-0120P-N2 5A MAG
L303 0LCML00003B MLB-201209-0120P-N2 5A MAG
L304 0LCML00003B MLB-201209-0120P-N2 5A MAG
L305 0LCML00003B MLB-201209-0120P-N2 5A MAG
L306 0LCML00003B MLB-201209-0120P-N2 5A MAG
L403 0LCML00003B MLB-201209-0120P-N2 5A MAG
L504 0LCML00003B MLB-201209-0120P-N2 5A MAG
L607 0LCML00003B MLB-201209-0120P-N2 5A MAG
L906 0LCML00003B MLB-201209-0120P-N2 5A MAG
L910 0LCML00003B MLB-201209-0120P-N2 5A MAG
L911 0LCML00003B MLB-201209-0120P-N2 5A MAG
F804 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F805 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F806 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F807 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F808 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F809 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F810 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F811 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F812 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F813 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F814 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F815 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
F816 6200QJ3001A "FILTER,EMI REEL/TAPING BMS4"
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L1001 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1002 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1003 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1004 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1006 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1007 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1011 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1018 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1021 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1022 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1023 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1024 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1032 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1033 0LCML00003B MLB-201209-0120P-N2 5A MAG
L106 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1104 0LCML00003B MLB-201209-0120P-N2 5A MAG
L200 0LCML00003B MLB-201209-0120P-N2 5A MAG
L201 0LCML00003B MLB-201209-0120P-N2 5A MAG
L311 0LCML00003B MLB-201209-0120P-N2 5A MAG
L316 0LCML00003B MLB-201209-0120P-N2 5A MAG
L317 0LCML00003B MLB-201209-0120P-N2 5A MAG
L318 0LCML00003B MLB-201209-0120P-N2 5A MAG
L319 0LCML00003B MLB-201209-0120P-N2 5A MAG
L400 0LCML00003B MLB-201209-0120P-N2 5A MAG
L401 0LCML00003B MLB-201209-0120P-N2 5A MAG
L402 0LCML00003B MLB-201209-0120P-N2 5A MAG
L503 0LCML00003B MLB-201209-0120P-N2 5A MAG
L600 0LCML00003B MLB-201209-0120P-N2 5A MAG
L601 0LCML00003B MLB-201209-0120P-N2 5A MAG
L602 0LCML00003B MLB-201209-0120P-N2 5A MAG
L603 0LCML00003B MLB-201209-0120P-N2 5A MAG
L604 0LCML00003B MLB-201209-0120P-N2 5A MAG
L606 0LCML00003B MLB-201209-0120P-N2 5A MAG
L900 0LCML00003B MLB-201209-0120P-N2 5A MAG
L901 0LCML00003B MLB-201209-0120P-N2 5A MAG
L902 0LCML00003B MLB-201209-0120P-N2 5A MAG
L903 0LCML00003B MLB-201209-0120P-N2 5A MAG
L904 0LCML00003B MLB-201209-0120P-N2 5A MAG
L905 0LCML00003B MLB-201209-0120P-N2 5A MAG
R800 0LCML00003B MLB-201209-0120P-N2 5A MAG
R801 0LCML00003B MLB-201209-0120P-N2 5A MAG
R803 0LCML00003B MLB-201209-0120P-N2 5A MAG
R804 0LCML00003B MLB-201209-0120P-N2 5A MAG
L1029 0LCML00020D MLI-201212-220K 22UH MAG LA
L103 0LC4732101A 4.7UH 10% 3216 R/TC FI-B321
L301 0LC3332101A 33UH 10% 3216 R/TC FI-D3216
L700 0LCML00020B MLI-201209-6R8K 6.8UH MAG
L102 0LC3332101A 33UH 10% 3216 R/TC FI-D3216
L1030 0LCML00020D MLI-201212-220K 22UH MAG LA
L1031 0LCML00020D MLI-201212-220K 22UH MAG LA
L1101 0LCML00020B MLI-201209-6R8K 6.8UH MAG
L1103 0LCML00020B MLI-201209-6R8K 6.8UH MAG
L300 0LCML00020B MLI-201209-6R8K 6.8UH MAG
L312 0LC1532101A 15UH 10% 3216 R/TC FI-C3216
L313 0LCML00019B SMI-322522-390K 39U MAG LAY
L701 0LCML00020B MLI-201209-6R8K 6.8UH MAG
L702 0LCML00020C MLI-201212-100K 10UH MAG LA
Q603 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q1000 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q1001 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q1002 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q1003 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q1004 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q1005 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q1006 0TR102009AM KRA102S KEC REEL TAPING SOT
Q1008 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q101 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q102 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q107 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q1100 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q1101 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
- 30 -
COIL & CORE & INDUCTOR
TRANSISTOR
