LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R192 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R193 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R2 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R4 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R101 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R102 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R103 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R104 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R105 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R106 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R107 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R109 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R11 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R110 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1100 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1102 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1106 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1107 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1109 0RH6800D622 680 OHM 1 / 10 W 2012 5.00%
R1112 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1114 0RH6800D622 680 OHM 1 / 10 W 2012 5.00%
R1115 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1116 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00
R1117 0RH1501D622 1.5K OHM 1 / 10 W 2012 5.00
R1118 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1119 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R112 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1123 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1124 0RH1501D622 1.5K OHM 1 / 10 W 2012 5.00
R1125 0RH7500D622 750 OHM 1 / 10 W 2012 5.00%
R1126 0RH7500D622 750 OHM 1 / 10 W 2012 5.00%
R1127 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R113 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1132 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1138 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1139 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R1140 0RH5601D622 5.6K OHM 1 / 10 W 2012 5.00
R1146 0RH5601D622 5.6K OHM 1 / 10 W 2012 5.00
R1148 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1149 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1151 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1152 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1157 0RH5601D622 5.6K OHM 1 / 10 W 2012 5.00
R1159 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R1160 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1164 0RH5601D622 5.6K OHM 1 / 10 W 2012 5.00
R1165 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1166 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R1168 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1169 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1170 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1171 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1173 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1174 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1176 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1177 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1178 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R118 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R1181 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R1182 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R1183 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1184 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R119 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1194 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R120 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R121 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R122 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R123 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R128 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R130 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R131 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R133 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R134 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R135 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R136 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R138 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R140 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R141 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R145 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R146 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R148 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R150 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R151 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R152 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R153 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R155 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R156 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R158 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R159 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R160 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R161 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R162 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R163 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R164 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R165 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R166 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R167 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R168 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R169 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R17 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R170 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R171 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R172 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R173 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R18 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R187 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R188 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R189 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R190 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R196 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R197 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R20 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R200 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R5 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R6 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R7 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R8 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R9 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
SW200 6634D00010D TASA-H303P LG INNOTEK 75 OH
X100 6212AB3004D CSALF2M69G4ZF01-A3 MURATA 2
X101 6212AB2015A HC-49/SM4H BUBANG 4MHZ +/-
SW101 140-313A TACT 2LEAD 100G(TA) LG C&D
SW102 140-313A TACT 2LEAD 100G(TA) LG C&D
SW103 140-313A TACT 2LEAD 100G(TA) LG C&D
SW104 140-313A TACT 2LEAD 100G(TA) LG C&D
SW105 140-313A TACT 2LEAD 100G(TA) LG C&D
SW106 140-313A TACT 2LEAD 100G(TA) LG C&D
SW107 140-313A TACT 2LEAD 100G(TA) LG C&D
SW108 140-313A TACT 2LEAD 100G(TA) LG C&D
R101 0RH1201D622 1.2K OHM 1 / 10 W 2012 5.00
R102 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00
R103 0RH2002D622 20K OHM 1 / 10 W 2012 5.00%
R104 0RH7501D622 7.5K OHM 1 / 10 W 2012 5.00
R105 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00
R106 0RH1201D622 1.2K OHM 1 / 10 W 2012 5.00
R107 0RH2002D622 20K OHM 1 / 10 W 2012 5.00%
R108 0RH7501D622 7.5K OHM 1 / 10 W 2012 5.00
ZD101 0DZ510009EE UDZ S 5.1B TP ROHM SOD323 -
ZD102 0DZ510009EE UDZ S 5.1B TP ROHM SOD323 -
- 38 -
KEY BOARD
OTHERs
