LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q300 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q301 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q302 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q303 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q304 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q305 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q600 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q601 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q602 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q901 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
IC904 0TF492509AA SI4925DY TP TEMIC 30V 6.1A
AR100 0RRZVTA001C 4.7K OHM 1 / 16 W 1608 5% R
AR1100 0RRZVTA001C 4.7K OHM 1 / 16 W 1608 5% R
AR1101 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1102 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR300 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR301 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR302 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR303 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR304 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR305 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR306 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR307 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR308 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR309 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR600 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR601 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR602 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR603 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR604 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR605 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR900 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR901 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR902 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR903 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR904 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR905 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR906 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR907 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR908 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR909 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR910 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR911 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR912 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
R10 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R100 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1000 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1001 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1002 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1003 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1005 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R1007 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R10076 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R10077 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R10078 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R10079 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R1009 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1010 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1018 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1020 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R1022 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1023 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R103 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1031 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R1039 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R104 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1045 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1046 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1055 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1059 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R106 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1060 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1062 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1063 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1066 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R107 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R108 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1087 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R1088 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R1089 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R109 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1090 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R1093 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1094 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1095 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1096 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R1097 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R11 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R110 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1102 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1104 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1105 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R111 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R113 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R114 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R115 0RJ6800D677 680 OHM 1/10 W 5% 1608 R/TP
R1151 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R1156 0RJ3001D677 3K OHM 1/10 W 5% 1608 R/TP
R1158 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1166 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1167 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R117 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1174 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1175 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R12 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R13 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R134 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R14 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R15 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R150 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R152 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R153 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R154 0RJ3901D677 3.9K OHM 1/10 W 5% 1608 R/T
R155 0RJ3901D677 3.9K OHM 1/10 W 5% 1608 R/T
R156 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R159 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R16 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R160 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R170 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R177 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R182 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R188 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R190 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R192 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R193 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R194 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R196 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R197 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R198 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R225 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R226 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R229 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/T
R230 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/T
R231 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/T
R249 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R250 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R251 0RJ1202D677 12K OHM 1/10 W 5% 1608 R/TP
R253 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R265 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R268 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R273 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R274 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R286 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R306 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R307 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
- 31 -
RESISTORs
