LG 42LC2D Service Manual

- 32 -
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R308 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R309 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R310 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R311 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R312 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R313 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R314 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R315 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R316 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R317 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R318 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R319 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R320 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R324 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R325 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R329 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R333 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R334 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R335 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R336 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R358 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R374 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R400 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R401 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R402 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R403 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R404 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R405 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R407 0RJ0272D677 27 OHM 1/10 W 5% 1608 R/TP
R408 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R409 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R410 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R411 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R414 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R415 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R416 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R417 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R418 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R423 0RJ1820D477 182 OHM 1/10 W 1% 1608 R/TP
R424 0RJ1820D477 182 OHM 1/10 W 1% 1608 R/TP
R431 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R437 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R438 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R441 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R442 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R443 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R507 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R508 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R515 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R564 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R609 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R614 0RJ1004D677 1000000 OHM 1/10 W 5% 1608
R626 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R627 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R628 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R647 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R654 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R656 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R661 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R713 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R717 0RJ0512D677 51 OHM 1/10 W 5% 1608 R/TP
R9 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R914 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R915 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R916 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R917 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R919 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R927 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R929 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R944 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R945 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R946 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R948 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R950 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R965 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R973 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R985 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R986 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R987 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R989 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R990 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB100 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB103 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
RB105 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB108 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB109 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB110 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB117 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
RB123 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB131 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
RB134 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
RB137 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB143 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
RB203 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
RB204 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
AR500 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR501 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR502 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR503 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR504 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR505 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR506 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR507 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR508 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR509 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR510 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR511 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR512 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR513 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR514 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
AR515 0RJ0332C605 33 OHM 1/16 W 5% 1608 ARRAY
R1 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R10000 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R10001 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R101 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1011 0RH0432D622 43 OHM 1 / 10 W 2012 5.00%
R1012 0RH0432D622 43 OHM 1 / 10 W 2012 5.00%
R1013 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R1015 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1016 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1017 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1019 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R102 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1021 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1024 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1025 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1026 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1027 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1029 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1030 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1033 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1034 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1035 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1036 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1037 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1038 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1040 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1041 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1042 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1047 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1049 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R105 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R1050 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1053 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1054 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1056 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1057 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R1058 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
