DATE: 2006. 02. 06.

*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION

R101 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R102 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R103 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R104 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R105 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R106 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

R107 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D

LED1 0DL200000CA SAM5670(DL-2LRG) BK Y-GREEN

PA101 6712000013A TSOP4438SO1 VISHAY 38KHZ AN

C101 0CH4471K416 470PF 50V 5% NP0 2012 R/TP

C102 0CH5101K416 100PF 50V 5% NP0 2012 R/TP

C103 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)

C104 0CH4471K416 470PF 50V 5% NP0 2012 R/TP

C105 0CH4471K416 470PF 50V 5% NP0 2012 R/TP

L101 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%

Q101 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -

Q102 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -

R101 0LCML00003B MLB-201209-0120P-N2 5A MAG

R102 0LCML00003B MLB-201209-0120P-N2 5A MAG

R103 0LCML00003B MLB-201209-0120P-N2 5A MAG

R104 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00

R105 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00

- 39 -

IR BOARD

SIDE BOARD
