LG 42LC2D Service Manual

- 8 -
8. RGB Iinput (PC/DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
PC
1 720x400 31.469 70.08 28.32 DOS O
2 640x480 31.469 59.94 25.17 VESA(VGA) O
3 640x480 37.861 72.80 31.50 VESA(VGA) O
4 640x480 37.500 75.00 31.50 VESA(VGA) O
5 800x600 35.156 56.25 36.00 VESA(SVGA) O
6 800x600 37.879 60.31 40.00 VESA(SVGA) O
7 800x600 48.077 72.18 50.00 VESA(SVGA) O
8 800x600 46.875 75.00 49.50 VESA(SVGA) O
9 1024x768 48.363 60.00 65.00 VESA(XGA) O
10 1024x768 56.476 70.06 75.00 VESA(XGA) O
11 1024x768 60.023 75.02 78.75 VESA(XGA) O
DTV
1. 720x480 31.47 59.94 SDTV 480P
2. 720x480 31.50 60 SDTV 480P
3. 1280x720 45.00 60.00 HDTV 720P
4. 1280x720 44.96 59.94 HDTV 720P
5. 1920x1080 33.75 60.00 HDTV 1080I
6. 1920x1080 33.72 59.94 HDTV 1080I
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
PC DDC
1. 640x480 31.469 59.94 25.17 VESA(VGA) O
2. 640x480 37.861 72.80 31.50 VESA(VGA) O
3. 640x480 37.500 75.00 31.50 VESA(VGA) O
4. 800x600 35.156 56.25 36.00 VESA(SVGA) O
5. 800x600 37.879 60.31 40.00 VESA(SVGA) O
6. 800x600 48.077 72.18 50.00 VESA(SVGA) O
7. 800x600 46.875 75.00 49.50 VESA(SVGA) O
8. 1024x768 48.363 60.00 65.00 VESA(XGA) O
9. 1024x768 56.476 70.06 75.00 VESA(XGA) O
10. 1024x768 60.023 75.02 78.75 O
DTV
11. 720x480 31.500 60 27.03 SDTV 480P
12. 720x480 31.469 59.94 27.00 SDTV 480P
13. 1280x720 45.00 60.00 HDTV 720P
14. 1280x720 44.96 59.94 HDTV 720P
15. 1920x1080 33.75 60.00 HDTV 1080I
16. 1920x1080 33.72 59.94 HDTV 1080I
