LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D115 0DD184009AA KDS184 TP KEC - 85V - - - 3
D106 0DD184009AA KDS184 TP KEC - 85V - - - 3
D100 0DZRM00218A UDZS8.2B ROHM R/TP SOD323 2
D101 0DZRM00218A UDZS8.2B ROHM R/TP SOD323 2
D102 0DZRM00218A UDZS8.2B ROHM R/TP SOD323 2
D103 0DZRM00218A UDZS8.2B ROHM R/TP SOD323 2
D104 0DZRM00218A UDZS8.2B ROHM R/TP SOD323 2
IC100 0IMMRAL014B AT24C02N-10SI-2.7 ATMEL 8P
IC101 0IMCRSO025A CXA2181Q SONY 48P QFP TRAY
IC103 0ISO206900A CXA2069Q QFP64 BK I2C BUS A
IC102 0IPH740800H "74F08D 14P,SOIC TP QUAD 2-I"
IC200 0IMCRSH001A "PQ05DZ1U SHARP 5, SMD TYPE"
IC201 0IMCRFA010A "KA7809R, FAIRCHILD 2P D-PAK"
IC104 0ISTL00024A "MC14053BDR2G,LF ON SEMI 16P"
L207 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L101 6210VC0005A BK2125 HS 750 TAIYOYUDEN 2X
L103 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L105 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L108 6210TCE001S HU-1M2012-121 CERATECH 2012
L110 6210TCE001S HU-1M2012-121 CERATECH 2012
L201 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L202 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L203 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L204 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L205 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L206 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L102 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L106 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L107 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L200 6210VC0006A FBMH3216 HM501NT TAIYOYUDEN
L100 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
L104 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
Q124 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q100 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q101 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q102 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q103 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q104 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q105 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q106 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q107 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q108 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q109 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q110 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q111 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q112 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q113 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q114 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q115 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q117 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q118 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q119 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q120 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q121 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q122 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q123 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q138 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q139 0TR102009AJ KRC102S KEC REEL TAPING SOT
Q141 0TR102009AJ KRC102S KEC REEL TAPING SOT
R126 0RN1002F409 10K OHM 1/6 W 1.00% TA52
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R10 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R100 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R108 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R1101 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1103 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1104 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1105 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1108 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R111 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R1110 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1111 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1113 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1120 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1121 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1122 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1128 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1129 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R1130 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1131 0RH1003D622 100K OHM 1 / 10 W 2012 5.00
R1133 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1134 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1135 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1136 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1137 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R114 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1141 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1142 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1143 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1144 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1145 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1147 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R115 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1150 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1153 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R1154 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
R1155 0RH3900D622 390 OHM 1 / 10 W 2012 5.00%
R1156 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1158 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R116 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1161 0RH3900D622 390 OHM 1 / 10 W 2012 5.00%
R1162 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1163 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1167 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R117 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R1172 0RH1003D622 100K OHM 1 / 10 W 2012 5.00
R1175 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R1179 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1180 0RH0682D622 68 OHM 1 / 10 W 2012 5.00%
R1185 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1187 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1189 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R1190 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1191 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1192 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R1193 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1195 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1196 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R12 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R124 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R125 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R127 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R129 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R13 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R137 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R139 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R14 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R149 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R15 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R154 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R157 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R16 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R186 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R19 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
- 37 -
RESISTORs
COIL & CORE & INDUCTOR
TRANSISTOR
DIODEs
IC
