LG 42LC2D Service Manual

DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C105 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C107 0CH5220K416 22PF 50V 5% NP0 2012 R/TP
C108 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C109 0CH5220K416 22PF 50V 5% NP0 2012 R/TP
C1105 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1106 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1107 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1108 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1109 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1110 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1117 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1120 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1124 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1125 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1127 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1128 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1130 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1132 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1136 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1139 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1142 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C1143 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C120 0CK105DF64A 1UF 2012 16V 20% F(Y5V) R/T
C122 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C127 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
C131 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C144 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C146 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C148 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C155 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C157 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C162 0CH5471K416 470PF 50V 5% NP0 2012 R/TP
C163 0CH5471K416 470PF 50V 5% NP0 2012 R/TP
C164 0CH5080K116 8PF 2012 50V 0.5 PF NP0 R/T
C165 0CH5080K116 8PF 2012 50V 0.5 PF NP0 R/T
C166 0CH5080K116 8PF 2012 50V 0.5 PF NP0 R/T
C202 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C205 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C207 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C209 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C210 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C211 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C218 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C219 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C220 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C227 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C228 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C101 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1126 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1137 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1138 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C114 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1140 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1141 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1152 0CH5471K416 470PF 50V 5% NP0 2012 R/TP
C1158 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C135 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C141 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C142 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C143 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C145 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C147 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C229 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C1118 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C112 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C113 0CH2472K516 4700PF 50V 10% B(Y5P) 2012
C1134 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C1135 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C1144 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C1145 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C1146 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C119 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C204 0CH2334F566 0.33UF 16V 10% X7R 2012 R/T
C212 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
DATE: 2006. 02. 06.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C213 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C214 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C221 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C222 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C223 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C102 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C104 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1103 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1147 0CH2222K516 2200PF 50V 10% B(Y5P) 2012
C1148 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1149 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C115 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1150 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1151 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C116 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C117 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C118 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C123 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C128 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C129 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C130 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C132 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C133 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C136 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C137 0CH2103K516 10000PF 50V 10% B(Y5P) 2012
C150 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C151 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C152 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C159 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C160 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C100 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C106 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1100 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1101 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1102 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1104 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) S
C1111 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1112 0CH8226F691 22UF 16V 20% 105STD (CYL) R
C1113 0CH8226F691 22UF 16V 20% 105STD (CYL) R
C1114 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1115 0CE225WK6DC "2.2UF MVK,RC 50V 20% SMD TA"
C1116 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1119 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1121 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) S
C1122 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1123 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) S
C1129 0CE225WK6DC "2.2UF MVK,RC 50V 20% SMD TA"
C1131 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C1133 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C1153 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) S
C1155 0CE105WK6DC 1UF MVK 50V 20% R/TP(SMD) S
C1156 0CE225WK6DC "2.2UF MVK,RC 50V 20% SMD TA"
C1157 0CE225WK6DC "2.2UF MVK,RC 50V 20% SMD TA"
C121 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C124 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C125 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C126 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C134 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C139 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C153 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C156 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C158 0CH8106F691 10UF 16V 20% 105STD (CYL) R
C161 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C203 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C206 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C208 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C215 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C216 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C217 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C224 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C225 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C226 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C230 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C231 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
