77
206-4281
Symptom
Possible Cause Possible Solution
Channel is blanked in all
channel banks.
Blanking a channel in one channel bank
will make it blank in all channel banks.
Modify the channel attribute(s), if desired, using the FTG
Channel Map Editor in the FTG File Manager. See also
“FTG Channel Map Editor” overview on page 51. Restore
normal operation by unchecking the “Blank Video”
checkbox for the channel. Note that normal operation
will be restored to the channel in all channel banks.
“Inactive TV” message
appears and then TV turns
OFF.
TV is set up to display “Inactive TV”
message if all channels are deleted from
Channel Bank 4.
Select another channel bank (1, 2, or 3) to return TV to
normal operation.
Channel found during Auto
Tuning does not tune in with
Channel Up/Down.
Channel was deleted in currently selected
channel bank.
Premium channels may only be available on another
channel bank. Modify the channel bank allocation(s) for
the channel, if desired, using the FTG Channel Map
Editor in the FTG File Manager. See also “FTG Channel
Map Editor” overview on page 51.
When CH. BANK on
Installer Remote is pressed,
TV shows Input List Menu.
Installer Menu item 027 HOSPITAL MODE
is set to 0.
Set item 027 to appropriate setting for channel banks to
appear with CH. BANK key presses.
Troubleshooting (Cont.)
Channel Banks Setup Troubleshooting

Table of Contents

Other manuals for LG 43LX570M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG 43LX570M and is the answer not in the manual?

LG 43LX570M Specifications

General IconGeneral
Panel life- h
Pixel pitch- mm
Response time8 ms
Display diagonal43 \
Display brightness- cd/m²
Display technologyLED
Contrast ratio (dynamic)1000000:1
Contrast ratio (typical)1200:1
Display number of colors-
USB version2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sound modesDynamic, Game, Music, News, Sports, Standard
RMS rated power10 W
Impedance8 Ω
Weight (without stand)9979.03214 g
AC input voltage110 - 127 V
AC input frequency60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)42 W
Product designDigital signage flat panel
Panel mounting interface200 x 200 mm
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth574.04 mm
Width972.82 mm
Height55.88 mm
