LG 47G2 - Wall Mounting Procedures and VESA Standards

23
ENG
ENGLISH
Installation
Mounting on a wall
Attachanoptionalwallmountbracketattherear
oftheTVcarefullyandinstallthewallmount
bracketonasolidwallperpendiculartothe
floor.WhenyouattachtheTVtootherbuilding
materials,pleasecontactqualifiedpersonnel.
WerecommendthatyouuseanLGbrandwall
mountwhenmountingtheTVtoawall.
10 cm
10 cm
10 cm (4 inches)
10 cm
Makesuretousescrewsandwallmountsthat
meettheVESAstandard.Standarddimensionsfor
thewallmountkitsaredescribedinthefollowing
table.
Model 47/55G2
VESA 400x400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW400BX,LSW400BXG

Disconnectthepowerfirst,andthenmove
orinstalltheTV.Otherwiseelectricshock
mayoccur.

IfyouinstalltheTVonaceilingorslanted
wall,itmayfallandresultinsevereinjury.
UseanauthorizedLGwallmountand
contactthelocaldealerorqualified
personnel.

Donotovertightenthescrewsasthismay
causedamagetotheTVandvoidyour
warranty.

Usethescrewsandwallmountsthatmeet
theVESAstandard.Anydamagesorinjuries
bymisuseorusinganimproperaccessory
arenotcoveredbythewarranty.
CAUTION

UsethescrewsthatarelistedontheVESA
standardscrewspecifications.

Thewallmountkitincludesaninstallation
manualandnecessaryparts.

Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.

Thelengthofscrewsmaydifferdepending
onthewallmount.Makesuretousethe
properlength.

Formoreinformation,refertothemanual
suppliedwiththewallmount.

Whenattachingathird-partywallmounting
brackettotheTV,insertthewallmount
innerspacersintotheTVwallmountholes
tomoveyourTVinverticalangle.Please
makesurenottousethespacersforLG
wallmountingbracket.
Wall Mount Inner Spacer
NOTE
