LG 47G2 - Component Connection

30
ENG
ENGLISH
Connections
Component Connection
TransmitstheanalogvideoandaudiosignalsfromanexternaldevicetotheTV.Connecttheexternal
deviceandtheTVwiththecomponentcableasshowninthefollowingillustration.

Ifcablesareinstalledincorrectly,itcouldcausetheimagetodisplayinblackandwhiteorwith
distortedcolor.

Check to ensure each cable is matched with the corresponding color connection.
NOTE
VIDEO
AUDIO
L R
DVD/ Blu-Ray / HD Cable Box
(Use the component video cable provided.)(Use the composite video cable provided.)
(*Not Provided)
(*Not Provided)
GREEN RED BLUE YELLOW
GREENYELLOW
WHITE RED
GREEN RED BLUE
GREEN RED BLUE WHITE RED
WHITE RED
IN
COMPONENT AV
VIDEO AUDIO Y P B P R
