EXTERNAL CONTROL DEVICE SETUP
22. Tile V Position (Command: d f)
To set the Vertical position.
Transmission
[d][f][ ][Set ID][ ][Data][Cr]
Data Min : 00H to Max : 14H
00H : Step -10(Down)
14H : Step 10(Up)
Acknowledgement
[f][ ][Set ID][ ][OK/NG][Data][x]
23. Tile H Size (Command: d g)
To set the Horizontal size.
Transmission
[d][g][ ][Set ID][ ][Data][x]
Data Min : 00H to Max : 64H
* Refer to 'Real data mapping ’. See p.51
Acknowledgement
[g][ ][Set ID][ ][OK/NG][Data][x]
24. Tile V Size (Command: d h)
To set the Vertical size.
Transmission
[d][h][ ][Set ID][ ][Data][x]
Data Min : 00H to Max : 64H
* Refer to 'Real data mapping ’. See p.51
Acknowledgement
[h][ ][Set ID][ ][OK/NG][Data][x]
19. Key (Command: m c)
To send IR remote key code.
Transmission
[m][c][ ][Set ID][ ][Data][Cr]
Data Key code : Refer to ‘IR CODES’. See p.46
Acknowledgement
[c][ ][Set ID][ ][OK][Data][x]
20. Tile Mode (Command: d d)
Change a Tile Mode.
Transmission
[d][d][ ][Set ID][ ][Data][Cr]
Data Description
00 or 11 Tile mode is off.
12 1 x 2 mode (column x row)
13 1 x 3 mode
14 1 x 4 mode
...
...
55 1 x 2 mode
* The data can not be set to 0X or X0 except 00.
Acknowledgement
[d][ ][Set ID][ ][OK/NG][Data][x]
21. Tile H Position (Command: d e)
To set the Horizontal position.
Transmission
[d][e][ ][Set ID][ ][Data][Cr]
Data Min : 00H to Max : 14H
00H : Step -10(Left)
14H : Step 10(Right)
Acknowledgement
[e][ ][Set ID][ ][OK/NG][Data][x]
