EXTERNAL CONTROL DEVICE SETUP
36. On Timer (On/Off Timer) Time (Command: f d)
Set On Timer.
Transmission
[f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]
[Data1]
1. f1h to f4h(read one index)
f1: read 1st index of On Time List
f2: read 2nd index of On Time List
f3: read 3rd index of On Time List
f4: read 4th index of On Time List
2. e1h~e4h(delete one index), e0h(delete all indexes)
e0: delete all indexes of On Time List
e1: delete 1st index of On Time List
e2: delete 2nd index of On Time List
e3: delete 3rd index of On Time List
e4: delete 4th index of On Time List
3. 01h to 80h (write) (Day of Week)
bit0 (01h) : Monday
bit1 (02h) : Tuesday
bit2 (04h) : Wednesday
bit3 (08h) : Thursday
bit4 (10h) : Friday
bit5 (20h) : Saturday
bit6 (40h) : Sunday
bit7 (80h) : Everyday
(1fh) : Monday to Friday
(3fh) : Monday to Saturday
(60h) : Saturday to Sunday
[Data 2]
00h to 17h (Hours)
[Data 3]
00h to 3bh (Minutes)
*When you read/delete the current on time list, all of
[Data2][Data3] are have to be FFH.
(ex1: fd 01 f1 ff ff - when you read 1st index of On
Time List
ex2: fd 01 e1 ff ff - when you delete 1st index of On
Time List
ex3: fd 01 3f 02 03 - when you write one On Time
Data, "Monday to Saturday, 02:03"
Acknowledgement
[d][ ][Set ID][ ][OK][Data1][Data2][Data3][x]
37. Off Timer (On/Off Timer) Time (Command: f e)
Set Off Timer.
Transmission
[f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]
[Data 1]
1. f1h to f4h(read one index)
f1: read 1st index of Off Time List,
f2: read 2nd index of Off Time List
f3: read 3rd index of Off Time List
f4: read 4th index of Off Time List
2. e1h to e4h(delete one index), e0h(delete all
indexes)
e0: delete all indexes of Off Time List
e1: delete 1st index of Off Time List
e2: delete 2nd index of Off Time List
e3: delete 3rd index of Off Time List
e4: delete 4th index of Off Time List
3. 01h to 80h (write) (Day of Week)
bit0 (01h) : Monday
bit1 (02h) : Tuesday
bit2 (04h) : Wednesday
bit3 (08h) : Thursday
bit4 (10h) : Friday
bit5 (20h) : Saturday
bit6 (40h) : Sunday
bit7 (80h) : Everyday
(1fh) : Monday to Friday
(3fh) : Monday to Saturday
(60h) : Saturday to Sunday
[Data 2]
00h to 17h (Hours)
[Data 3]
00h to 3bh (Minutes)
*When you read/delete the current on time list, all of
[Data2][Data3] are have to be FFH.
(ex1: fd 01 f1 ff ff - when you read 1st index of Off
Time List
ex2: fd 01 e1 ff ff - when you delete 1st index of Off
Time List
ex3: fd 01 3f 02 03 - when you write one Off Time
Data, "Monday to Saturday, 02:03")
Acknowledgement
[e][ ][Set ID][ ][OK][Data1][Data2][Data3][x]
