12 INSTALLATION
Specifications
Appliance
• Dimensions are given for the assembled product body, extension pipe and nozzle.
• Battery run time is the result of using a fully charged battery according to the LG Electronics test
standard. Results may be different depending on actual use environment and period of use.
• Recommended maximum run time when using the mop nozzle is 80 minutes. Otherwise, the motor may
overheat.
† The Nozzle contains the direct drive motor that rotates the nozzle cleaning head directly.
Charging Station
Storing the Accessories
Assembling and Storing the
Appliance
Follow these steps to safely assemble the
appliance.
1 Firmly attach the extension pipe c, nozzle d,
or tool onto the product body a.
• To detach the extension pipe, press the
extension pipe release button
b.
2 Put the product body on the charging station.
• If the vacuum cleaner fits properly inside
the charging station, the alarm will sound.
Wait several seconds and if the alarm does
Model A9**********
Dimensions
(Width X Depth X
Height)
10.2 in X 10.6 in X 44.1 in
260 mm X 270 mm x 1120 mm
Weight Approximately 5.95 lb (2.7 kg)
Power Consumption 370 W in Turbo Mode (Maximum 590 W)
120 W in Power Mode
68 W in Normal Mode
Battery Run Time
(Using two battery)
Using with the Nozzle
†
Up to 12 minutes in Turbo Mode
Up to 40 minutes in Power Mode
Up to 80 minutes in Normal Mode
Using with the Tool
Up to 14 minutes in Turbo Mode
Up to 60 minutes in Power Mode
Up to 120 minutes in Normal Mode
Battery Run Time
(Using one battery)
Using with the Nozzle
†
Up to 6 minutes in Turbo Mode
Up to 20 minutes in Power Mode
Up to 40 minutes in Normal Mode
Using with the Tool
Up to 7 minutes in Turbo Mode
Up to 30 minutes in Power Mode
Up to 60 minutes in Normal Mode
Model VDS-ST1****
Input 120 V~ 60 Hz
Output DC 28.3 V / 1.15 A
Power Consumption 9 A (Cleaning)
0.6 A (Charging)
