BACnetCommissionBACnetCommission
Commissioningistheprocessofverifyingthesubsystemstoachievetheowner'sprojectrequirementsasintendedbythebuildingownerandasdesignedbythe
buildingarchitectsandengineers.
AfterACSmart5installation,youcanchecktheoperationstatusofthedevicebyusingthewebfunctionbeforeconnectionwiththeBMSsystem.
CreatingofthePoints.ThisisNOTtobedonebyLGsinceitisdirectlyrelatedtotheBMSside.TheBMSengineeristocarryouttheengineeringofthePoint,
howeverLGisresponsibleforprovidingthemethodofhowthePointsarecalculated.
PrecautionsPrecautions
TouseBACnetfeature,youmustselect[Settings]>[BACnet/ModbusSetting]>[BACnetenable][Settings]>[BACnet/ModbusSetting]>[BACnetenable]asSetSet.
Incaseofinstalling2ormoreACSmart5,youmustchange[Settings]>[BACnet/ModbusSetting]>[DeviceIDSetting][Settings]>[BACnet/ModbusSetting]>[DeviceIDSetting]sothattheDeviceIDsarenot
duplicateamongACSmart5.Itisrecommendedthatyoukeepadifferenceof10ormorefordifferentDeviceIDs.
IfDeviceDiscoverdoesn'tworkwell,change[Settings]>[BACnet/ModbusSetting]>[BACnetTypeSetting][Settings]>[BACnet/ModbusSetting]>[BACnetTypeSetting].
ItisrecommendedthatyourequestReadProperty/WritePropertyatanintervalof200msormoreforeachproperty.
ItisrecommendedthatyourequestReadPropertyMultiple/WritePropertyMultipleatanintervalof500msormoreforeachproperty.
SubscribeCOVcanberegisteredupto1024.
IfACSmart5andBMSarelocatedondifferentnetworks,BBMD(BACnet/IPBroadcastManagementDevice)isneeded.
AsACSmart5doesnotsupporttheBBMDfunction,aseparateBBMDisrequired.YoucanregisterACSmart5asaforeigndeviceinBBMDusing[Settings]>[Settings]>
[BACnet/ModbusSetting]>[RegisterasForeignDevice][BACnet/ModbusSetting]>[RegisterasForeignDevice]function.
UserManualUserManual
