LG AC Smart 5 User Manual

ConnectACSmart5ConnectACSmart5
YoucaninstallACSmart5anditscablesasfollows.
1.ChooseaspaceforACSmart5.
-PriortosecuringACSmart5,checkifthespaceissuitableforinstallingACSmart5,anRS485cable,powercord,andanEthernetcable.
2.SecurethebackpanelofACSmart5tothewallunderwhichtheRS485cableislocated.
3.ExtendtheRS485cablethroughthetopopeningofthebackpanel.
4.ConnecttheRS485cable,whichislocatedbehindtheACSmart5,totheRS485terminal.
CAUTIONCAUTION
TheRS485cablehaspolarity,sobecarefulaboutkeepingpolaritywhenconnectingthecables.TheRS485cablehaspolarity,sobecarefulaboutkeepingpolaritywhenconnectingthecables.
5.Tousethenetworkfunctions(emailtransmissionandwebcontrol)providedbyACSmart5,connectanEthernetcabletotheLANportonthebackofACSmart5.
UserManualUserManual

LG AC Smart 5 Specifications

General

Cooling Capacity	1.5 Ton
Star Rating	5 Star
Refrigerant	R32
Type	Split Air Conditioner
Features	Auto Clean
EER	3.5
Warranty	1 Year Comprehensive, 10 Years on Compressor
