LG AC Smart 5 User Manual

NameofEachPartNameofEachPart
ACSmart5iscomposedasthefollowingform.
No.No. CategoryCategory ContentsContents
① TouchScreen
•10.2inchLCDcontrolpanel
•ACSmart5controlandinformationdisplay
② SDMemorySlot SDcardmemoryslot
③ DOPort 2CHDOport
④ DIPort 2CHDIport
⑤ RS-485Port
2CH485port(CH1:AHU,CH2:devicesotherthanAHU)
•CH1defaultsetting:LGAP_AHU/CH2defaultsetting:LGAPI
•Tochangedefaultsetting,refertothecontentsof'DeviceSetting-ACSmart5Editing'intheusermanualprovidedin[Help]category.
⑥ 12V InputPort 12V powerinputport
⑦ LANPort LANcableportforEthernetconnection(100Mbps/10Mbps)
⑧ 24V~InputPort 24V~powerinputport
⑨
MicroUSBPort(for
service)
Portforupgradingsoftwareandstoringfloorplans,reports,statistics,etc.(ItneedscabletoconnectUSBmemorysticks,supportingUSB2.0or
later)
⑩ MiniUSBPort PCportfordebuggingsoftware
⑪ PowerON/OFF
•Ifyoupresslessthan9seconds,ACSmart5LCDbacklightcontrol
•Push10secondsormoretoresetACSmart5.
•IfyouarenotgoingtouseACSmart5foralongtime,itisrecommendedthattheproductbeturnedofftoprolongtheLCDbacklight'slife.
UserManualUserManual
