62
Multi V Wall-Mounted Indoor Unit
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
CONTROLS SETUP
Figure 67: Remote Control
FAU FAU StandardStandard
FAU: Fresh Air Intake Unit
Standard: Standard Indoor Unit
ZC: Zone Controller
StandardStandard
Correct Control Wiring Incorrect Control Wiring
ZC ZC
Figure 66: Control Wiring with Standard IDU and Fresh Air Unit
Remote Control
Figure 67 shows an example of a control configuration with a remote sensor.
Remote
Sensor
Display
Error
Message
Master
Master
AC Smart
ACP Bacnet/ACP LON
(Optional)
Other Building
Mgmt System
(Optional)
LGMV
LGAP Network System
GNDSignal12V
Dry
Contact
(Optional)
To Next Page
