LG ARNU243SCL4 - Standard Wall-Mounted External Dimensions

46 | STANDARD
MULTI V Wall-Mounted Indoor Unit Engineering Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
STANDARD WALL-MOUNTED
([WHUQDO'LPHQVLRQV
Figure 28: ARNU053SBL4, ARNU073SBL4, ARNU093SBL4, ARNU123SBL4, ARNU153SBL4 Dimensions.
SB Frame
Display and Signal Receiver
Front Panel
Air Inlet Grille
Installation Plate
Access Hole
11-7/16
2
8-5/16
1-13/16
35-1/4
13-7/16 12-3/4 5-1/16
1-1/2
31-1/8
8-1/16
26-5/8
12-7/8
16-5/8
10-7/16
2-13/16
Unit: inches
Note: All measurements
have a tolerance of 1/4 in.
Access Hole
