LG BD370 - Component (Ypbpr) Video out

3-34
Copyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Component video no display
4. COMPONENT (YPbPr) VIDEO OUT
Re-soldering
YES
NO
L906 +3.3V
OK?
Re-soldering
YES
NO
C913, C914, C915
Signal OK?
Re-soldering
YES
NO
R923, R924, R925
Signal OK?
Re-soldering
YES
NO
JK904
Soldering OK?
Component Video OK
ELECTRICAL TROUBLESHOOTING GUIDE
