LG BD370 - Cvbs Video out

3-35
Copyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
CVBS video no display
IC301 Check
YES
NO
5. CVBS VIDEO OUT
C910
Video signal input
OK?
IC901 Check
YES
NO
R913
Video signal output
OK?
Re-soldering
YES
NO
JK904
Soldering OK?
CVBS Video OK
ELECTRICAL TROUBLESHOOTING GUIDE
