LG BH4530D - Specifications

Appendix 67
Appendix
6
Specifications
General
Power requirements Refer to main label
Power consumption Refer to main label
Dimensions (W x H x D) Approx. 360 mm x 60.5 mm x 304 mm
Net Weight (Approx.) 2.5 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector) x 1
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Power output (3 Ω/ 4 Ω), (RMS), THD 10 %
Total 204 W
Front 42 W x 2
Sub-Woofer 120 W (Passive)
